Kubota L01 Series 2501 4WD HST

Stock #D3100
MSRP: $19,995 USD
Pricing Notes: The price does not include the loader
Check Availability

Hi, my name is and I'm interested in this 2022 Kubota L01 Series 2501 4WD HST . I'm in the area and you can reach me at or by phone at

Available Color


  • Orange
  • Status:
    New
  • Vehicle:
    2022 Kubota L01 Series 2501 4WD HST
  • VIN:
    KBUL6DHREN8CD3100
  • Model Number:
    L2501HST
  • Color:
    Orange
  • Stock Number:
    D3100
  • Title:
    Clear
  • Location:
    Santa Fe Motor Sports
  • Warranty:
    Manufacturer's w/ Extended Available

BRAKES

  • Front Brake Type:
    Wet Disc
  • Rear Brake Type:
    Wet Disc

DRIVE LINE

  • Driveline Type:
    4X4

ENGINE

  • Aspiration:
    Natural
  • Bore (in):
    3.4
  • Bore (mm):
    87
  • Carburetion Type:
    Fuel Injected
  • Cooling:
    Liquid
  • Cylinders:
    3
  • Displacement (ci):
    100.47
  • Displacement (l):
    1.6
  • Engine Model Code:
    D1703-M-DI-E4-LB1
  • Fuel Type:
    Diesel
  • Horsepower (bhp):
    24.8
  • Horsepower (kW):
    18.5
  • Horsepower RPM:
    2200
  • Stroke (in):
    3.6
  • Stroke (mm):
    92.4

EXTERIOR

  • Platform Layout:
    Open

HYDRAULIC SYSTEM

  • Hydraulic Type:
    Open Center
  • Implement Pump Output (gpm):
    5.2
  • Implement Pump Output (lpm):
    19.5
  • Number of Optional Remote Valves:
    3
  • Pump Capacity (gpm):
    8.3
  • Pump Capacity (lpm):
    31.3
  • Rear 3-Point Hitch Category:
    Category 1
  • Rear 3-Point Hitch Lift Capacity (kgs):
    870
  • Rear 3-Point Hitch Lift Capacity (lbs):
    1918
  • Steering Pump Output (gpm):
    3.1
  • Steering Pump Output (lpm):
    11.8

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge

PTO

  • PTO Horsepower (bhp):
    19
  • PTO Horsepower (kW):
    14.2
  • PTO Location(s):
    Rear
  • PTO Type:
    Live
  • Rear PTO RPM:
    540

STEERING

  • Steering Type:
    Power

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    1190
  • Dry Weight (lbs):
    2623
  • Front Tread Width (in):
    43.1
  • Front Tread Width (mm):
    1095
  • Fuel Capacity (gal):
    10
  • Fuel Capacity (l):
    38
  • Ground Clearance (in):
    13.4
  • Ground Clearance (mm):
    340
  • Height (in):
    91.7
  • Height (mm):
    2330
  • Length (ft):
    8.86
  • Length (ft/ft):
    8
  • Length (ft/in):
    10.3
  • Length (in):
    106.3
  • Length (mm):
    2700
  • Max Front Tread Width (in):
    43.1
  • Max Front Tread Width (mm):
    1095
  • Max Rear Tread Width (in):
    50.8
  • Max Rear Tread Width (mm):
    1290
  • Rear Tread Width (in):
    43.8
  • Rear Tread Width (mm):
    1115
  • Turning Radius (ft):
    8.2
  • Turning Radius (m):
    2.5
  • Wheelbase (in):
    63.3
  • Wheelbase (mm):
    1610
  • Width (in):
    55.1
  • Width (mm):
    1400

TRANSMISSION

  • Clutch Type:
    Dry
  • Maximum Forward Speed (kph):
    18.5
  • Maximum Forward Speed (mph):
    11.5
  • Number of Ranges:
    3
  • Transmission Type:
    Hydrostatic

WHEELS & TIRES

  • Front Tire (Full Spec):
    Goodyear Power Torque 7.2-16 F2
  • Front Tire Width:
    7.2
  • Front Wheel Diameter:
    16
  • Rear Tire (Full Spec):
    Titan Hi Power Lug 11.2 - 24 R1
  • Rear Tire Width:
    11.2
  • Rear Wheel Diameter:
    24
  • Tread Type:
    Agricultural
  • Wheels Composition:
    Steel

Our Location


Santa Fe Motor Sports
2594 Camino Entrada
Santa Fe, NM 87507

Unit Disclaimer:

The price does not include the loader
